CISCO Small Business 100 Series

Categorie:

Cisco Small Business 100 Series Wireless Access Points
Simplify deployment with affordable Wi-Fi

WAP125

WAP150

WAP121

WAP131

Processor, Memory, and Storage

Hard drive – Hard drive – Hard drive – Hard drive –
RAM installed (max)256 MB RAM installed (max)256 MB RAM installed (max)64 MB RAM installed (max)128 MB
Flash memory installed (max)128 MB Flash memory installed (max)128 MB Flash memory installed (max)16 MB Flash memory installed (max)128 MB

Networking

Form factorABS material Form factor Form factorABS material Form factor
Connectivity technologyWireless AC Connectivity technologyWireless AC Connectivity technologyWireless N Connectivity technology
Data transfer rateUp to 867 Mbps Data transfer rate867 + 300 Mbps Data transfer rate300 Mbps Data transfer rate300 Mbps per radio
Line coding format – Line coding format – Line coding format – Line coding format –
Data link protocolIEEE 802.11a/b/g/n, IEEE 802.11ac Data link protocolIEEE 802.11a/b/g/n, IEEE 802.11ac Data link protocolIEEE 802.11b/g/n Data link protocolIEEE 802.11a/b/g/n
DFS supportNo DFS supportYes DFS supportNo DFS supportNo
Spread spectrum method Spread spectrum method Spread spectrum methodOFDM Spread spectrum method
Remote management protocolSNMPv3, HTTP, HTTPS Remote management protocolSNMPv3, HTTP, HTTPS Remote management protocolSNMPv3, HTTP, HTTPS Remote management protocol
Network and transport protocolDHCP, Bonjour Network and transport protocolDHCP, Bonjour Network and transport protocolDHCP, Bonjour Network and transport protocol
Frequency band2.4 GHz and 5 GHz Frequency band2.4 GHz and 5 GHz Frequency band2.4 GHz Frequency band2.4 GHz and 5 GHz
Number of radios1 Number of radios2 Number of radios1 Number of radios2
Multiple input, multiple output (MIMO)2 x 2:2 for 2.4 Ghz and 5 GHz or 1×1 on both 2.4 Ghz and 5 GHz Multiple input, multiple output (MIMO)2 x 2:2 for 2.4 Ghz and 5 GHz Multiple input, multiple output (MIMO)2 x 2:2 Multiple input, multiple output (MIMO)2 x 2:2 for 2.4 Ghz and 5 GHz
Maximum active WLAN clients16 Maximum active WLAN clients16 per radio Maximum active WLAN clients16 Maximum active WLAN clients16 per radio
Number of access points supported per clusterNone Number of access points supported per cluster4 Number of access points supported per cluster4 Number of access points supported per clusterNone
Status indicatorsOne LED power, WLAN, LAN Status indicatorsOne LED power, WLAN, LAN Status indicatorsPower, WLAN, LAN Status indicatorsPower, WLAN, LAN
FeaturesDHCP support, load balancing, VLAN support, syslog support, email alert, IPv6, Wireless Distribution System (WDS), firmware upgradable, Spanning Tree Protocol (STP), Wi-Fi Multimedia (WMM), access control list (ACL), quality of service (QoS), RADIUS, multiple SSID, wireless bridge mode, Wireless Scheduler, IPv4, rogue access point detection, captive portal lite, band steering FeaturesDHCP support, load balancing, VLAN support, syslog support, email alert, IPv6, Wireless Distribution System (WDS), firmware upgradable, wall mountable, Spanning Tree Protocol (STP), Wi-Fi Multimedia (WMM), access control list (ACL), quality of service (QoS), RADIUS, multiple SSID, wireless bridge mode, Wireless Scheduler, IPv4, rogue access point detection, captive portal, band steering, Single Point Setup FeaturesDHCP support, load balancing, VLAN support, syslog support, email alert, IPv6 , Wireless Distribution System (WDS) support, firmware upgradable, wall mountable, Spanning Tree Protocol (STP), Wi-Fi Multimedia (WMM) support, access control list (ACL) support, quality of service (QoS), RADIUS support, Wi-Fi Protected Setup (WPS), multiple SSID support, wireless bridge mode, IPv4 support, rogue access point detection, captive portal, Single Point Setup FeaturesDHCP support, load balancing, VLAN support, syslog support, email alert, IPv6 ,Wireless Distribution System (WDS) support, firmware upgradable, wall mountable, Spanning Tree Protocol (STP), Wi-Fi Multimedia (WMM) support, access control list (ACL) support, quality of service (QoS), RADIUS support, multiple SSID support, wireless bridge mode, IPv4 support
Roaming802.11r (when supported by driver) Roaming Roaming802.11r (when supported by driver) Roaming
Encryption algorithmWPA Personal, WPA Enterprise Encryption algorithm Encryption algorithmWPA Personal, WPA Enterprise Encryption algorithm
Authentication method Authentication method Authentication methodRADIUS, Radio Service Set ID (SSID) Authentication method
Compliant standardsIEEE 802.3, IEEE 802.3u, IEEE 802.1Q, IEEE 802.11a/b/d/e/g/i/n, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.1X, IEEE 802.11ac Compliant standardsIEEE 802.3, IEEE 802.3u, IEEE 802.1Q, IEEE 802.11a/b/d/e/g/i/n, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.1X, IEEE 802.11ac Compliant standardsIEEE 802.3, IEEE 802.3u, IEEE 802.1Q, IEEE 802.11b/d/e/g/i/n, IEEE 802.3af, IEEE 802.1X, Wi-Fi Protected Setup Compliant standardsIEEE 802.3, IEEE 802.3u, IEEE 802.1Q, IEEE 802.11a/b/d/e/g/i/n, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.1X

Antennas

Antenna2 x internal PIFA Antenna4 x internal PIFA Antenna2 x internal  PIFA Antenna4 x internal PIFA
Antenna quality – Antenna quality – Antenna quality – Antenna quality –
Directivity – Directivity – Directivity – Directivity –
Gain level3 dBi at 2.4 GHz, 4 dBi at 5 Ghz Gain level3.61 dBi at 2.4 GHz, 3.85 dBi at 5 Ghz Gain level2 dBi Gain level3.4 dBi on 2.4 GHz, 4.5 dBi on 5 GHz
